Automatic level AL200


  • Air-dampened X shape wire-hung compensator
  • Anti-vibrations and shocks
  • Smooth rotation horizontal knobs on both sides
  • Endless horizontal fine motion drive
  • Excellent sealed structure for all-weather condition
  • 5/8″ X11 thread fits standard tripod center
  • Plate suit for both flat and dome h,ead of tripod
  • water and dust proof IP54
SKU: 240002 Category:


Technical Parameters AL24 AL28 AL32
Standard Deviation for 1 km Double-run Leveling 2.0rnm 1.5mm 1.0mm
Telescope Magnification 24x 28x 32x
Telescope Image Erect
Effective Aperture Size of Object Lens 40mm
Field of View 1°20
Shortest Sighting Distance O.5m
Stadia Multiplication 100
Addition Constants 0
Compensator Type X wire-hung and air-damping
Compensator Working range ±15′
leveling Accuracy ±0.5″ ±0.4″ ±0.3″
Accuracy of Circular level ±8’/2mm
Horizontal Circle 360°or 400Gon optional
Instrument Size 1 88mm x 132mm x 140mm
Net. Weight 1.5kg
Standard Accessories Adjusting Pin, Hex key, Desiccating
Agent. Plastic Carry Case, Plumb
Bob, User Manual
Packing Details 4sets per Carton: 10kgs per Carton
